Itasca Automation Systems is the North America distributor for TPC Technology Products Company. TPC has been manufacturing winders for nearly 30 years based out of Slovakia.
TPC has a range of large winders like the ERN 100 up to ERN 500 winding machines. The free standing winders can handle from 40 awg to 00 awg wire.
The TPC Winders offer two different types of controls. The touch screen control is shown below. They also offer the G version control which has a built in keyboard for programming. The winders also have different options in wire guides as well as tension heads.
Itasca is a exclusive distributor for these winders and I think it will be a good idea to allow our potential customer to go to the website for more details on the ERN winders.
More Product Information
| Model | Spindle Speed Max RPM |
Torque | Pitch Resolution |
Traverse Length |
Max Coil Diameter |
Power Supply | Coil Weight Max |
|---|---|---|---|---|---|---|---|
| ERN 100 | 600 / 300 | 110 / 220 | .0003" | 15" / 31" / 39" / 47" | 23" / 30" / 36" | 400 Volt 3 Phase | 880 lbs |
| ERN 150 | 300 / 150 | 110 / 220 | .0003" | 15" / 31" / 39" / 47" | 23" / 30" / 36" | 400 Volt 3 Phase | 880 lbs |
| ERN 200 | 150 / 75 | 200 / 400 | .0003" | 15" / 31" / 39" / 47" | 23" / 30" / 36" | 400 Volt 3 Phase | 880 lbs |
| ERN 500 | 150 / 75 | 590 / 1180 | .0003" | 31" / 39" / 47" | 30" / 36" | 400 Volt 3 Phase | 2,200 lbs |
